Super 16m and 18m Long Boom for PC200/PC210/PC240
Super 16m and 18m Long Boom for PC200/PC210/PC240
Super 16m and 18m Long Boom for PC200/PC210/PC240
Super 16m and 18m Long Boom for PC200/PC210/PC240
Super 16m and 18m Long Boom for PC200/PC210/PC240
Super 16m and 18m Long Boom for PC200/PC210/PC240
Super 16m and 18m Long Boom for PC200/PC210/PC240

Super 16m and 18m Long Boom for PC200/PC210/PC240

Product Details

Certification: CE, ISO9001: 2000

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 9500

Get Best Price
Contact Now

Specifications

Description
Specifications
Highlight:

PC200 excavator long boom arm

,

18m excavator extended reach boom

,

PC240 long arm with warranty

Model NO.:
PC200/PC210/PC240
Material:
Q355b(S355) And Q690d(S690ql)
Boom Length:
8700mm
Arm Length:
6800mm
Max Dig Depth:
11370mm
Max Extensive Scope:
15300mm
Max Dig Height:
10300mm
Folding Height:
2980mm
Bucket Capacity:
0.5m3
Suit Excavator Tonnage:
20ton
Max Unloading Height:
9510mm
Min Rotate Radius:
4500mm
Counter Weight:
1 Ton
Production Capacity:
1000set/Year
Pin Material:
42CrMo4
Model NO.:
PC200/PC210/PC240
Material:
Q355b(S355) And Q690d(S690ql)
Boom Length:
8700mm
Arm Length:
6800mm
Max Dig Depth:
11370mm
Max Extensive Scope:
15300mm
Max Dig Height:
10300mm
Folding Height:
2980mm
Bucket Capacity:
0.5m3
Suit Excavator Tonnage:
20ton
Max Unloading Height:
9510mm
Min Rotate Radius:
4500mm
Counter Weight:
1 Ton
Production Capacity:
1000set/Year
Pin Material:
42CrMo4
Description
Super 16m and 18m Long Boom for PC200/PC210/PC240
Super 16m and 18m Long Boom for PC200/PC210/PC240
Super 16m and 18m Long Boom for PC200/PC210/PC240 0 Super 16m and 18m Long Boom for PC200/PC210/PC240 1 Super 16m and 18m Long Boom for PC200/PC210/PC240 2
Certification & Documentation
  • CE and ISO certified
  • PDF brochure available
Packing & Shipping
  • Initial film wrapping with steel wire securing inside container
  • Container capacity: 3 complete sets (using racks for upper sets)
  • Production lead time: 15 days for 1 set, 25 days for 3 sets
Technical Specifications
Super 16m and 18m Long Boom for PC200/PC210/PC240 3
Boom length 8700 mm
Arm length 6800 mm
Max extensive scope (A) 15100 mm
Max dig depth (B) 11340 mm
Max dig height (D) 12510 mm
Max dig depth in vertical wall (C) 10268 mm
Max unloading height (E) 9510 mm
Min rotate radius (F) 4500 mm
Bucket volume 0.6 m3
Counter weight 1 ton
Folding height 2980 mm
Applications
  • Construction projects requiring long reach excavators
  • Road construction
  • Successfully exported to Russia
Product Features
Designed for dredging, port construction, railway construction and groundwork with high operation scope, efficiency and security
10+ years experience in designing and customizing long reach booms for all excavator brands
Compatible with all excavator models, including OEM services
Advanced manufacturing processes meeting global standards
Customizable based on your excavator's installation dimensions
Premium materials: Q345B + Q690D steel with 42CrMo4 pins (Weldox optional)
Complete package includes lubricant pipe system, hydraulic system, bucket, cylinder, linkage, pins and hoses
Precision edge milling before welding for enhanced structural performance
Optional extra pipeline for specialized applications
Flexible cylinder options to reduce costs
Reinforced plates available for heavy-duty applications
80% Argon and 20% CO2 protective gas welding for superior quality
Precision boring of main structures to eliminate welding stress tolerance
6-month warranty with comprehensive parts list for maintenance
Export Documentation
Super 16m and 18m Long Boom for PC200/PC210/PC240 4 Super 16m and 18m Long Boom for PC200/PC210/PC240 5
