Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser

China Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser supplier
Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser supplier Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser supplier Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser supplier Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser supplier

Large Image :  Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser

Product Details:

Place of Origin: China
Brand Name: Haide
Certification: CE/ISO
Model Number: HD-YYJ200-CAT330

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: Film,plywood box,plywood pallet
Delivery Time: Within 30 days
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description
Name: Demolition Shear,Crusher,Pulverizer Suitable Excavator: 20~40 Ton
Base Material: Q345B Main Body Material: Hardox450
Jaw Material: 80mm Thick Hardox450 Weight: 2200 Kg

Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser



Description:



      We can customize all kinds of demolition shears for all kinds of excavators.



      Hydraulic demolition shears also called demolition crusher,multi-processor,etc.It’s composed with main

body, hydraulic cylinder, movable jaw .The external hydraulic system offer hydraulic pressure for the

hydraulic cylinder to make the two movable jaws open and close to achieve the effect of crushing concreted

walls.Mainly function is for both primary and secondary demolition work.



Our Demoliton crusher shear have follow advantages:

1. The 2pcs jaws is made from 80mm thick hardox450 steel,much more longer life than cast jaw.

2. We use boring machine adjust the precision after welding,to avoid the big tolerance leaded by welding

stress.

3. Both the main-body and jaws are made from  hardox450,structure is high performance

4. Blade is 2pcs 4-side blade,so have a much more longer life

5. The blade of this demolition shear,can cut 30mm-diameter steel rod,can cut 30mm-thick steel sheet.

6. Rotate motor is two stage planetary reducer hydraulic pump,much more higher rotate speed,better than worm gear pump.

7. Hydraulic oil cylinder is equipped with a protective cover to obstruct the splash of concrete and

steel debris.

8. The grease injection nipples have cover protected,won’t be damaged in rough demolition work.





Specification:



Excavator tonnage 20~40 ton
Self Weight 2200 kg
Max Open 980 mm
Max cutting force 2250 KN
Rotate 360 degree

Oil flow needed for cutting

190~260L/min

Oil flow needed for rotating

20L/min

Main body material

Hardox450

Jaw material

80mm thick Hardox450

Blade

2pcs 4 side blade

Rotate motor two stage planetary reducer hydraulic pump






Application:



1. Demolishing brick concrete buildings.

2. Demolishing steel concrete buildings.

3. Pull rebar out of concrete for recycling business.





Workshop pictures:



Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser



Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser



Cat Pillar 330 Excavator Rotate Demolition Shears / Crusher / Pulveriser
