| Purpose: | Loading And Unloading Goods | Width: | 2200mm |
|---|---|---|---|
| Total Length: | 11050mm | Safety Fence Height: | 80mm |
| Capacity: | 10ton To 15ton Optional | Material Of Main Body: | Q235B(SGC490) |
| Adjust Range: | 1200~1650mm | Warranty: | 1 Year For Hydraulic System, 3 Year For Steel Structure |
| Delivery Time: | 15 Days | Color: | Optional |
| High Light: | 2200mm Width Mobile Yard Ramp,Unloading Mobile Yard Ramp,Mobile Loading Yard Ramp |
||
Mobile Yard Ramp 2200mm Width With 10 Ton Capacity Q235B
Application
1, Loading and unloading cargos for Container and Truck
Others
1, This container ramp was exported to Malaysia.
2, Need to use 40' container to ship it. one 40' container can load 3pcs.
| Width | 2200mm |
| Total length | 11050mm |
| Capacity | 10ton |
| Adjust range | 1200~1650mm |
| Material |
Q235B(SGC490) |
| Manual pump | Import from Italy, brand is " Oiltec" |
| Ramp weight | 3300kg |
| Warranty | 1 year for hydraulic system, 3 years for steel structure |
| Color | Optional |
Description:
1, We have 16 years experience in designing and customize the dock/mobile ramp as per customer’s
requirement.
2, Two moveable lip design facilitate the free lateral floating when the truck box floor move up and down
3, Two hydraulic retractable leg help to sustain the passage of heavy load during operation.
4, Two solid tyres provide excellent traction without worry of puncture.
5, The end bracket enable our dock ramp to be towable by forklift.
6, Capacity: 10ton and 15ton optional.
7, Steel grating on the slope floor prevent the forklift from slipping back during operation.
8, Top flat table is made of anti-skid steel plate.
9, We use Germany “BUCHER” hydraulic pump(optional) and it enable our yard ramp to be operated manually
with great ease, eliminating the need for electrical operation.
10, Tapered lip edge provide a smooth transition between container and ramp.
11, Two safety chain secure the fixing between ramp and truck box.
12, Hydraulic pump adjust the ramp to the desired position.
13, Guard rail(curb) provide safety and direction for forklift movement.
14, Two rubber bumper absorb the shock between truck box and ramp.
15, The dimension for every part can be customized to suit to actual demand.
