Home ProductsHydraulic Dock Leveler

ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler

Good quality Excavator Long Arm for sales
Good quality Excavator Long Arm for sales
I'm Online Chat Now

ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler

China ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler supplier
ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler supplier ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler supplier ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler supplier ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler supplier ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler supplier

Large Image :  ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler

Product Details:

Place of Origin: China
Brand Name: Haide
Certification: CE/ISO
Model Number: HD-HGT10-1

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation(EXW,FOB or CIF price)
Packaging Details: film,and put it directly to container.
Delivery Time: 15 days
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Platform Width: 1830mm Platform Length: 1830mm
Height: 490mm Dynamic Capacity: 10 Ton
Adjust Range: +300mm/-300mm Main Deck Thickness: 8mm
Lip Board Thickness: 16mm Power Pack: Italy "Hydr-APP" 0.75 Kw 340~415V 3p 50Hz
Oil Seal: Japan"Nok" Color: Optional

ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler





Description:


Equipment Specification(W*L*H): 1830mm*1830mm*490mm
Pit Dimension(W*L*H): 1870mm*1680mm*500mm
Dynamic Capacity: 10 ton
Adjust range: +300mm/-300mm
Main deck thickness: 8mm
Lip board thickness: 16mm
Power pack: : Italy "Hydr-APP" 0.75 KW 340~415V 3P 50Hz
Oil seal: Japan"NOK"
Color: Main body Red+Safety Black&Orange
Color: Optional
Warranty: 365 days after installation for all, 5 years warranty for the steel structure.

CE No.: DGS12082902

1 We can manufacture the dock ramp with capacity 10ton up to 25ton.
2 We can manufacture it as per your any requirements.

3 The 3-fragment full range toe-guard can prevent the operator from entering into the dock leveler by accident and prevent any damage and casualty to the operator.

4 Operation process: Push "UP" button, platform begin to rise. When it rise to highest point, push "EXTEND" button, lip extend out. Then press "DOWN" button, platform and lip lower down to rest on the truck box bed. When loading&unloading is over, then press "UP" botton, platform and lip begin to rise. When platform and lip get away from the truck box bed, then press "RETRACTION" button, lip retract. The push "DOWN" button, then dock leveler restore to original stored position.

5 Two laminated rubber bumper with woven fiber inside can withstand any shock between the truck and dock.

6 Meets all possible user demand and comply with rules and regulations of European EN1398 standards.
ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler

ISO Stationary Automatic Dock Levelers , Air Powered Dock Leveler



Specifications:



Model Specification(W*L*H)mm Pit Dimension(W*L*H)mm   Adjust range Lip board(W*L*T)
6*6 1830*1830*490 1870*1680*500   +300mm/-300mm 1830*400*15
6.5*6 1980*1830*490 2020*1680*500 1980*400*15
7*6 2130*1830*490 2170*1680*500 2130*400*15
6*8 1830*2440*490(590) 1870*2280*500(600) 1830*400*15
6.5*8 1980*2440*490(590) 2020*2280*500(600) 1980*400*15
7*8 2130*2440*490(590) 2170*2280*500(600) 2130*400*15
6*10 1830*3050*490(590) 1870*2880*500(600) +400mm/-300mm
If the height is 590mm:
+450mm/-350mm
1830*400*15
6.5*10 1980*3050*490(590) 2020*2880*500(600) 1980*400*15
7*10 2130*3050*490(590) 2170*2880*500(600) 2130*400*15
